IP PVM Monitor
LCD Panel Parameter
n Diagonal dimension：10.1 inch
n Backlight Type：LED backlight
n Display Area：216.96mm(H)x135.6mm(V)
n Resolution：1280x800
n Screen Ratio：16：10
n Pixel：0.1695mm(H)x0.1695mm(V)
n Display Color：Full Color
n Brightness：350cd/m2
n Contrast ratio：1000：1
n Response time：30ms
n View angle: 80°/80°/80°/80°（L/R/U/D）
Camera Module Parameter
n Sensor Type：1/2.9" Progressive Scan CMOS
n Main Chip: Hisilicon Hi3516CV300
n Electronic shutter：1/25s - 1/10000s
n Minimum illumination：Color 0.1Lux@F1.2 Black/white 0.01Lux@F1.2
n Signal-to-noise ratio：≥50dB(AGC OFF)
n Day night conversion mode：Photosensitive detection/Video detection/Time detection
n dynamic range：≥80dB
n Noise reduction：3D Digital noise reduction
Video Output Parameter
n Video compression standard：H.265+/H.265/H.264/MJPEG
n H.265 Coding type：Main Profile
n Video rate：32 Kbps~16Mbps
n Audio compression format：G.711a/ G.711u/G.726
n Video resolution：Main stream 1080P/720P
Auxiliary code stream D1（704x576）/VGA（640x480）/640x352
Whole Machine Parameter
n Signal input： VGAx1 / HDMIx1
n Signal output： RJ45x1
n Storage：TF slot x1
n Power input：DC 12V
n Whole machine consumption：≤15W
n Working Temperature： 0℃~50℃
n Storage Temperature：-10℃~60℃
n Environment Humidity：10%~90%
